Altistart 22 soft starter - ATS22 - control 220V-power 230V(90kW)/400...440V(160kW) - ATS22C32Q
This product is part of the Modicon TM3 range, an offer of expansion I/O modules for Modicon M221, M241, M251 and M262.
The analogue output module provides 2 outputs with 11bit + sign and 12bit resolution.
It is an output module with a rated supply voltage of 24V DC and a current consumption of 70mA at 24V DC via external supply full load.
This product is capable of controlling variable speed drives or any device equipped with a current or voltage input.
There is an insulation between output and supply at 1500V AC, output and internal logic at 500V AC.
It is furnished with removable screw terminal for electrical connection with 5.08mm pitch adjustment for outputs.
It is an IP20 rated product.
Its dimensions are 23.6mm (Width) x 70mm (Depth) x 90mm (Height).
It weighs 0.115kg.
This product is certified by CE.
It meets EN/IEC 61131-2 and EN/IEC 61010-2-201 standards.
This module is compatible with Modicon M262, Modicon M241, Modicon M251 and Modicon M221 logic controller.
It supports top hat type TH35-15, top hat type TH35-7.5 rail conforming to IEC 60715 and plate or panel with fixing kit mount.
Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism.
A bus expansion connector is used to distribute data and the power supply when assembling the Modicon TM3 modules with logic controllers.
Boost the performance of your controller with the Modicon TM3 I/O system specially designed for the Modicon M221, M241 and M251 logic controllers.
| Attribute | Value |
|---|---|
| SKU | ATS22C32Q |
| product certifications | CCC, GOST, CSA, UL, C-Tick |
| relative humidity | 0-95 % without condensation or dripping water conforming to EN/IEC 60068-2-3 |
| ambient air temperature for storage | -25-70 °C |
| pollution degree | level 2 conforming to IEC 60664-1 |
| ambient air temperature for operation | -10-40 °C (without derating), 40-60 °C (with current derating 2.2 % per °C) |
| range of product | Altistart 22 |
| operating position | vertical +/- 10 degree |
| product or component type | Soft Starter & Variable Speed Drive |
| net weight | 33 kg |
| standards | EN/IEC 60947-4-2 |
| range | Altivar Softstarter ATS22 |
| [Uc] control circuit voltage | 230 V - 15...10 % 50/60 Hz |
| minimum switching current | 100 mA at 12 V DC (relay outputs) |
| power range | 55-100 kW at 200-240 V 3 phases, 110-220 kW at 380-440 V 3 phases |
| motor starter type | soft starter |
| [Us] rated supply voltage | 230...440 V - 15...10 % |
| electromagnetic compatibility | conducted and radiated emissions level A conforming to IEC 60947-4-2, damped oscillating waves level 3 conforming to IEC 61000-4-12, electrostatic discharge level 3 conforming to IEC 61000-4-2, immunity to electrical transients level 4 conforming to IEC 61000-4-4, immunity to radiated radio-electrical interference level 3 conforming to IEC 61000-4-3, voltage/current impulse level 3 conforming to IEC 61000-4-5 |
| device connection | in the motor supply line, to the motor delta terminals |
| IcL starter rating | 320 A for connection in the motor supply line for standard applications |
| control circuit consumption | 20 W |
| factory setting current | 285 A |
| discrete output type | relay outputs R1 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O, relay outputs R2 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O |
| PTC probe input | 750 Ohm |
| network frequency | 45...66 Hz |
| height | 425 mm |
| power dissipation in W | 150 W for standard applications |
| marking | CE |
| width | 206 mm |
| depth | 299 mm |
| vibration resistance | 1 gn (f= 13-200 Hz) conforming to EN/IEC 60068-2-6, 1.5 mm (f= 2-13 Hz) conforming to EN/IEC 60068-2-6 |
| operating altitude | <= 1000 m without derating, > 1000...< 2000 m with current derating of 2.2 % per additional 100 m |
| IP degree of protection | IP00 |
| product destination | asynchronous motors |
| protection type | phase failure: line, thermal protection: motor, thermal protection: starter |
| connector type | 1 RJ45 |
| utilisation category | AC-53A |
| motor power kW | 160 kW 400 V, 160 kW 440 V, 90 kW 230 V |
| supply frequency | 50...60 Hz - 10...10 % |
| shock resistance | 15 gn for 11 ms conforming to EN/IEC 60068-2-27 |
| function available | internal bypass |
| network number of phases | 3 phases |
| supply voltage limits | 195-484 V |
| communication port protocol | Modbus |
| product specific application | pumps and fans |
| output current | 0.4...1 Icl adjustable |
| maximum switching current | 5 A 250 V AC resistive 1 relay outputs, 5 A 30 V DC resistive 1 relay outputs, 2 A 250 V AC inductive 0.4 20 ms relay outputs, 2 A 30 V DC inductive 7 ms relay outputs |
| discrete input voltage | 24 V <= 30 V |
| type of start | start with torque control (current limited to 3.5 In) |
| installed device | 31 |
| communication data link | serial |
| discrete output number | 2 |
| noise level | 56 dB |
| discrete input type | (LI1, LI2, LI3) logic, 5 mA 4.3 kOhm |
| physical interface | RS485 multidrop |
| type of cooling | forced convection |
| discrete input number | 3 |
| assembly style | with heat sink |
| transmission rate | 4800, 9600 or 19200 bps |
| discrete input logic | positive logic LI1, LI2, LI3 at State 0: < 5 V and <= 2 mA at State 1: > 11 V, >= 5 mA |
| component name | ATS22 |
